ERF12-FA4C-02BPVC
M12 Dişi, 90° Açılı, 4 Pin, PVC, 2 Metre, 4 x 0,22 mm²
- Açıklama
- Ek bilgi
Açıklama
Technical Data
| Standard | IEC 61076 | Contact Carriers Material | PU / PA |
| Series | M12, Female, Angled | Contact Material | Copper Alloy, Gold-Plated |
| Number of Pins | 04, 05 Pin | Metal of Nut | Copper Alloy with Nickel Plated |
| Rated Current | 3A max. | Seal | Silicone |
| Rated Voltage | 60V max. | Cable Jacket Material | PUR / PVC |
| Insulation Resistance | 100M | Color | Optional |
| Contact Resistance | -5m | Shielding | Optional |
| Ambient Temperature | -25 ~ +75°C | Mechanical Life | > 100 Mating Cycles |
| IP Class | IP67 | - | - |
| ARTICLE NO | TYPE | ANGLE | PIN | CABLE LENGTH | COLOR | CABLE TYPE | CABLE SECTION |
|---|---|---|---|---|---|---|---|
| ERF12-FA4C-02BPVC | F - FEMALE | A - ANGLED | 4 PİN | 2 METERS | BLACK | PVC / PUR | 4 x 0,22 mm² |
| ERF12-FA4C-03BPVC | F - FEMALE | A - ANGLED | 4 PİN | 3 METERS | BLACK | PVC / PUR | 4 x 0,22 mm² |
| ERF12-FA4C-05BPVC | F - FEMALE | A - ANGLED | 4 PİN | 5 METERS | BLACK | PVC / PUR | 4 x 0,22 mm² |
| ERF12-FA4C-10BPVC | F - FEMALE | A - ANGLED | 4 PİN | 10 METERS | BLACK | PVC / PUR | 4 x 0,22 mm² |
| ERF12-FA5C-02BPVC | F - FEMALE | A - ANGLED | 5 PİN | 2 METERS | BLACK | PVC / PUR | 5 x 0,22 mm² |
| ERF12-FA5C-03BPVC | F - FEMALE | A - ANGLED | 5 PİN | 3 METERS | BLACK | PVC / PUR | 5 x 0,22 mm² |
| ERF12-FA5C-05BPVC | F - FEMALE | A - ANGLED | 5 PİN | 5 METERS | BLACK | PVC / PUR | 5 x 0,22 mm² |
| ERF12-FA5C-10BPVC | F - FEMALE | A - ANGLED | 5 PİN | 10 METERS | BLACK | PVC / PUR | 5 x 0,22 mm² |
| ERF12-FA4B-02BPVC | F - FEMALE | A - ANGLED | 4 PİN | 2 METERS | BLACK | PVC / PUR | 4 x 0,34 mm² |
| ERF12-FA4B-03BPVC | F - FEMALE | A - ANGLED | 4 PİN | 3 METERS | BLACK | PVC / PUR | 4 x 0,34 mm² |
| ERF12-FA4B-05BPVC | F - FEMALE | A - ANGLED | 4 PİN | 5 METERS | BLACK | PVC / PUR | 4 x 0,34 mm² |
| ERF12-FA4B-10BPVC | F - FEMALE | A - ANGLED | 4 PİN | 10 METERS | BLACK | PVC / PUR | 4 x 0,34 mm² |
| ERF12-FA5B-02BPVC | F - FEMALE | A - ANGLED | 5 PİN | 2 METERS | BLACK | PVC / PUR | 5 x 0,34 mm² |
| ERF12-FA5B-03BPVC | F - FEMALE | A - ANGLED | 5 PİN | 3 METERS | BLACK | PVC / PUR | 5 x 0,34 mm² |
| ERF12-FA5B-05BPVC | F - FEMALE | A - ANGLED | 5 PİN | 5 METERS | BLACK | PVC / PUR | 5 x 0,34 mm² |
| ERF12-FA5B-10BPVC | F - FEMALE | A - ANGLED | 5 PİN | 10 METERS | BLACK | PVC / PUR | 5 x 0,34 mm² |
Ek bilgi
| Kod | A Kod |
|---|
